DATEL ADC-207LM-C 7位高速CMOS閃存型模數轉換器ADC

發布時間：2025-11-10 09:07:22 瀏覽：208

　　ADC-207是由 DATEL推出的 7位高速CMOS閃存型模數轉換器(Flash ADC)，采用 1.2μm VLSI CMOS 工藝制造，具備低功耗、高線性度、優異的溫度穩定性等特點，適用于高速信號采集、雷達、通信和醫療設備等應用場景。

DATEL ADC-207LM-C 7位高速CMOS閃存型模數轉換器ADC

　　型號參數

Part Number	Resolution	Sampling Rate	Power Consumption	Package Type	Operating Temp. Range (min)	Operating Temp. Range (max)
ADC-207LC	7 Bit	20 MHz	0.25 W	24-pin CLCC	0 oC	+70 oC
ADC-207LC-C	7 Bit	20 MHz	0.25 W	24-pin CLCC	0 oC	+70 oC
ADC-207LE	7 Bit	20 MHz	0.25 W	24-pin CLCC	-40 oC	+100 oC
ADC-207LE-C	7 Bit	20 MHz	0.25 W	24-pin CLCC	-40 oC	+100 oC
ADC-207LM	7 Bit	20 MHz	0.25 W	24-pin CLCC	-55 oC	+125 oC
ADC-207LM-C	7 Bit	20 MHz	0.25 W	24-pin CLCC	-55 oC	+125 oC
ADC-207LM-QL	7 Bit	20 MHz	0.25 W	24-pin CLCC	-55 oC	+125 oC
ADC-207LM-QL-C	7 Bit	20 MHz	0.25 W	24-pin CLCC	-55 oC	+125 oC
ADC-207MC	7 Bit	20 MHz	0.25 W	18-pin DIP	0 oC	+70 oC
ADC-207MC-C	7 Bit	20 MHz	0.25 W	18-pin DIP	0 oC	+70 oC
ADC-207ME	7 Bit	20 MHz	0.25 W	18-pin DIP	-40 oC	+100 oC
ADC-207ME-C	7 Bit	20 MHz	0.25 W	18-pin DIP	-40 oC	+100 oC
ADC-207MM	7 Bit	20 MHz	0.25 W	18-pin DIP	-55 oC	+125 oC
ADC-207MM-C	7 Bit	20 MHz	0.25 W	18-pin DIP	-55 oC	+125 oC
ADC-207MM-QL	7 Bit	20 MHz	0.25 W	18-pin DIP	-55 oC	+125 oC
ADC-207MM-QL-C	7 Bit	20 MHz	0.25 W	24-pin CLCC	-55 oC	+125 oC
